LaTeX Figure Commands: Images, Graphics and Visual Elements

LaTeX figure commands provide sophisticated tools for including and managing images, graphics, and visual elements in professional documents. This comprehensive guide covers all essential figure handling commands, from basic image inclusion to advanced layout techniques that create publication-quality visual presentations.

Understanding LaTeX Figure Commands Structure

LaTeX figure commands operate through two main components: the \includegraphics command for importing images and the figure environment for positioning, scaling, and captioning. This systematic approach ensures consistent formatting and professional presentation of visual content.

The basic structure combines these elements:

\begin{figure}[positioning]
    \centering
    \includegraphics[options]{filename}
    \caption{Figure caption}
    \label{fig:reference}
\end{figure}

Understanding this framework is essential for effectively using LaTeX figure commands in academic and professional documents.

Basic Image Inclusion Commands

The \includegraphics command forms the foundation of all LaTeX figure commands.

Essential Graphics Package

Before using any LaTeX figure commands, include the graphics package:

\usepackage{graphicx}

This package provides the \includegraphics command and all associated image handling functionality.

Simple Image Inclusion

\includegraphics{image.jpg}         % Basic image inclusion
\includegraphics{image.png}         % Works with PNG files
\includegraphics{image.pdf}         % PDF graphics (vector)
\includegraphics{path/to/image}     % Images in subdirectories

LaTeX automatically detects supported file formats, including JPEG, PNG, PDF, and EPS files depending on your compilation method.

Image Scaling and Sizing Commands

LaTeX figure commands provide multiple options for controlling image dimensions and scaling.

Width-Based Scaling

\includegraphics[width=5cm]{image}              % Fixed width
\includegraphics[width=0.5\textwidth]{image}    % Relative to text width
\includegraphics[width=0.8\linewidth]{image}    % Relative to line width
\includegraphics[width=\columnwidth]{image}     % Full column width

Height-Based Scaling

\includegraphics[height=4cm]{image}             % Fixed height
\includegraphics[height=0.3\textheight]{image} % Relative to page height

Scale Factor Sizing

\includegraphics[scale=0.5]{image}              % 50% of original size
\includegraphics[scale=1.2]{image}              % 120% of original size
\includegraphics[scale=0.75]{image}             % 75% of original size

Combined Scaling Options

\includegraphics[width=5cm,height=3cm]{image}           % Fixed dimensions
\includegraphics[width=5cm,height=3cm,keepaspectratio]{image}  % Maintain aspect ratio

The keepaspectratio option ensures images don’t become distorted when both width and height are specified.

Figure Environment and Positioning

The figure environment provides LaTeX figure commands for proper placement and captioning of visual content.

Basic Figure Environment

\begin{figure}[htbp]
    \centering
    \includegraphics[width=0.6\textwidth]{myimage}
    \caption{Descriptive caption for the figure}
    \label{fig:example}
\end{figure}

Positioning Options

h       % Here (approximately at current position)
t       % Top of page
b       % Bottom of page
p       % Separate page for floats only
!       % Override LaTeX positioning restrictions
H       % Exactly here (requires float package)

Example with specific positioning:

\begin{figure}[!htbp]   % Try here first, then top, bottom, page

Figure Captions and Labels

\caption{Main figure caption}
\caption*{Unnumbered caption}                    % Requires caption package
\caption[Short]{Long descriptive caption}       % Short version for list of figures
\label{fig:unique-identifier}                   % For cross-referencing

Advanced Image Manipulation

LaTeX figure commands include sophisticated options for image transformation and positioning.

Image Rotation

\includegraphics[angle=90]{image}               % Rotate 90 degrees
\includegraphics[angle=45,width=5cm]{image}     % Combined rotation and scaling
\includegraphics[origin=c,angle=180]{image}     % Rotate around center

Rotation origins:

c – center (default)
l – left edge
r – right edge
t – top edge
b – bottom edge

Image Clipping and Trimming

\includegraphics[clip,trim=1cm 2cm 3cm 4cm]{image}     % Trim: left bottom right top
\includegraphics[viewport=50 50 200 150]{image}        % Show specific region

Advanced Scaling Options

\includegraphics[totalheight=5cm]{image}               % Total height including depth
\includegraphics[resolution=300]{image}                % Set DPI resolution

Subfigures and Complex Layouts

Create sophisticated figure arrangements using subfigure commands.

Basic Subfigures

\usepackage{subcaption}

\begin{figure}[htbp]
    \centering
    \begin{subfigure}{0.45\textwidth}
        \centering
        \includegraphics[width=\textwidth]{image1}
        \caption{First subfigure}
        \label{fig:sub1}
    \end{subfigure}
    \hfill
    \begin{subfigure}{0.45\textwidth}
        \centering
        \includegraphics[width=\textwidth]{image2}
        \caption{Second subfigure}
        \label{fig:sub2}
    \end{subfigure}
    \caption{Main caption for both subfigures}
    \label{fig:main}
\end{figure}

Complex Subfigure Layouts

\begin{figure}[htbp]
    \centering
    % Top row
    \begin{subfigure}{0.3\textwidth}
        \includegraphics[width=\textwidth]{image1}
        \caption{Image 1}
    \end{subfigure}
    \hfill
    \begin{subfigure}{0.3\textwidth}
        \includegraphics[width=\textwidth]{image2}
        \caption{Image 2}
    \end{subfigure}
    \hfill
    \begin{subfigure}{0.3\textwidth}
        \includegraphics[width=\textwidth]{image3}
        \caption{Image 3}
    \end{subfigure}

    % Bottom row
    \begin{subfigure}{0.45\textwidth}
        \includegraphics[width=\textwidth]{image4}
        \caption{Larger image 4}
    \end{subfigure}
    \hfill
    \begin{subfigure}{0.45\textwidth}
        \includegraphics[width=\textwidth]{image5}
        \caption{Larger image 5}
    \end{subfigure}

    \caption{Complex subfigure arrangement}
\end{figure}

Text Wrapping and Inline Figures

Integrate figures with text flow using specialized LaTeX figure commands.

Wrapping Figures

\usepackage{wrapfig}

\begin{wrapfigure}{r}{0.4\textwidth}
    \centering
    \includegraphics[width=0.35\textwidth]{image}
    \caption{Wrapped figure on right}
\end{wrapfigure}

This text will wrap around the figure on the right side of the page.

Positioning options for wrapfigure:

r – right side
l – left side
R – right side, may float
L – left side, may float

Inline Graphics

This text contains an inline image \includegraphics[height=\baselineskip]{small-icon}
within the paragraph.

% For mathematical diagrams
The function graph \includegraphics[height=2\baselineskip,valign=c]{graph} shows the relationship.

Figure Referencing and Cross-References

Proper referencing is essential for professional documents using LaTeX figure commands.

Basic References

\begin{figure}[htbp]
    \includegraphics[width=0.6\textwidth]{diagram}
    \caption{System architecture diagram}
    \label{fig:architecture}
\end{figure}

As shown in Figure~\ref{fig:architecture}, the system consists of three main components.

Advanced Referencing

\usepackage{cleveref}

% Automatic reference types
\cref{fig:architecture}         % "Figure 1"
\Cref{fig:architecture}         % "Figure 1" (capitalized)
\crefrange{fig:first}{fig:last} % "Figures 1 to 3"

Subfigure References

Figure~\ref{fig:main} shows the complete system, while \ref{fig:sub1}
highlights the input module and \ref{fig:sub2} shows the output interface.

Graphics Path Management

Organize image files efficiently using path management commands.

Setting Graphics Paths

\graphicspath{{images/}{figures/}{./graphics/}}

This allows you to use:

\includegraphics{myimage}       % Searches in specified directories

Instead of:

\includegraphics{images/myimage}

Multiple Path Configuration

\graphicspath{%
    {images/}%
    {figures/}%
    {../shared-images/}%
    {./diagrams/}%
}

Creating Figures with TikZ

LaTeX figure commands can include programmatically created graphics using TikZ.

Basic TikZ Figure

\usepackage{tikz}

\begin{figure}[htbp]
    \centering
    \begin{tikzpicture}
        \draw (0,0) rectangle (3,2);
        \draw (0,0) -- (3,2);
        \draw (3,0) -- (0,2);
        \node at (1.5,1) {TikZ};
    \end{tikzpicture}
    \caption{Simple TikZ diagram}
    \label{fig:tikz}
\end{figure}

Combining Images and TikZ

\begin{figure}[htbp]
    \centering
    \begin{tikzpicture}
        \node[anchor=south west,inner sep=0] (image) at (0,0)
              {\includegraphics[width=0.6\textwidth]{photo}};
        \begin{scope}[x={(image.south east)},y={(image.north west)}]
            \draw[red,ultra thick,rounded corners] (0.1,0.1) rectangle (0.9,0.9);
            \node at (0.5,0.05) {Highlighted region};
        \end{scope}
    \end{tikzpicture}
    \caption{Annotated photograph}
    \label{fig:annotated}
\end{figure}

Figure Formatting and Styling

Customize figure appearance using advanced LaTeX figure commands.

Custom Caption Formatting

\usepackage{caption}

\captionsetup{
    font=small,
    labelfont=bf,
    textfont=it,
    justification=centering,
    singlelinecheck=false
}

Figure Borders and Frames

\usepackage{fancybox}

\begin{figure}[htbp]
    \centering
    \fbox{\includegraphics[width=0.5\textwidth]{image}}
    \caption{Figure with border}
\end{figure}

% Fancy borders
\begin{figure}[htbp]
    \centering
    \shadowbox{\includegraphics[width=0.5\textwidth]{image}}
    \caption{Figure with shadow}
\end{figure}

Troubleshooting Common Issues

File Format Problems

Issue: Images not appearing Solution: Check supported formats by compilation method:

PDFLaTeX: JPG, PNG, PDF
LaTeX + DVI: EPS, PS

Path Issues

Issue: File not found errors Solution: Use forward slashes even on Windows:

\includegraphics{images/myfile.jpg}     % Correct
\includegraphics{images\myfile.jpg}     % Incorrect on some systems

Size and Positioning Problems

Issue: Images too large or poorly positioned Solution: Use relative sizing:

\includegraphics[width=0.8\textwidth,keepaspectratio]{image}

Best Practices for LaTeX Figure Commands

File Organization

Keep images in dedicated directories
Use descriptive filenames
Maintain consistent image formats within documents

Caption Writing

Write descriptive, informative captions
Include enough detail for standalone understanding
Use consistent caption formatting throughout

Referencing Strategy

Always label figures for cross-referencing
Use meaningful label names: \label{fig:system-architecture}
Reference figures in the text to guide readers

Technical Considerations

Use vector formats (PDF, SVG converted to PDF) when possible
Optimize image file sizes for document compilation speed
Test figure placement with different document lengths

Conclusion

LaTeX figure commands provide comprehensive tools for including and managing visual content in professional documents. From basic image inclusion to complex subfigure arrangements and custom styling, these commands ensure your visual elements are presented with the same high quality as your text content.

Master the fundamental \includegraphics command and figure environment first, then progressively add advanced features like subfigures, wrapping text, and custom formatting. The systematic approach to figure management in LaTeX produces consistent, professional results that enhance the overall impact of your documents.

Remember that effective figure use involves both technical proficiency with commands and good design principles – choose appropriate sizes, write informative captions, and ensure figures support rather than distract from your content.
